Panel Kits /
Gear Edge
Gear Edge
Panel Kits
94
ONE
YEAR
Gear Edge Panel
Kits in Aluminium
GEP6 / GEP7 / GEP8
Gear Edge panel folding kits and
counters are strong, robust and
easy to transport, even with graphics
in situ. The durable aluminium
Gear Edge frame system is suitable
for permanent displays. Panels are
available as frame only, or with a
choice of fabric colours or with your
own designed graphic infill panels,
offering you the flexibility that best
suits your requirements.
- Aluminium Gear Edge hinges
allow the frame to be positioned
at any angle
- Silver anodised frames are
quick and easy to assemble
- Choice of three counter styles
to complement your stand
Gear Edge
Counters
GECS / GECC / GECD
Gear Edge Straight Counter
Gear Edge Curved Counter
Gear Edge 8 Panel Kit
Gear Edge 7 Panel Kit Gear Edge 6 Panel Kit
Panel kits Visible graphic area (approx.): Code
6 Panel kit
6 Header
867(h) x 556(w) mm
217(h) x 556 (w) mm
GEP6-96FO/FC
7 Panel kit
7 Header
867(h) x 556 (w) mm
217 (h) x 556 (w) mm GEP7-96FO/FC
8 Panel kit
8 Header
867 (h) x 556 (w) mm
217 (h) x 556 (w) mm x 2 GEP8-96FO/FC
FO: Frame only / FC: Fabric covered
Total hardware dimensions (approx.):
6 panel - 1500 (h) x 2050 (w) mm
7 panel - 2050 (h) x 1500 (w) mm
8 panel - 2050 (h) x 2100 (w) mm
Counter kits Visible graphic area
(approx.):
Code
Straight front panel
Straight side panel
867 (h) x 685 (w) mm
867 (h) x 315 (w) mm GECS-FO/FC
Curve front panel:
Curve side panel:
867 (h) x 712 (w) mm
867 (h) x 315 (w) mm GECC-FO/FC
Display front panel:
Display side panel:
622 (h) x 685 (w) mm
622 (h) x 136 (w) mm GECD-FO/FC
FO: Frame only / FC: Fabric covered
Total hardware dimensions (approx.):
Straight - 920 (h) x 830 (w) x 450 (d) mm
Curved - 920 (h) x 830 (w) x 525 (d) mm
Display - 920 (h) x 775 (w) x 405 (d) mm Gear Edge Display Counter
Lockable cupboard door for
extra security optional
Optional carry bags
and panel lighting
available, see our
accessories section
from page 127
